Child lockJLWM14071400900500700Delay startDoor lockStart/PauseQuickExtra rinseIntensivePrewashRinse holdStainSpinNoneWash timeColdHand washDrainRinseO

10In the interest of the environmentWashing machines and dishwashers should beconnected to the FOUL drainage system, the water willthen be taken to a

11Electrical connectionAny electrical work required to install this applianceshould be carried out by a qualified electrician orcompetent person.WARNI

121 Detergent dispenser drawer2 Programme selector dialThe programme selector dial is divided into thefollowing sections:• Cottons,• Synthetics,• Deli

13Programme options buttonsDepending on the programme, different functions canbe combined. These must be selected after choosingthe desired programme

148 Display (Wash time)The following pieces of information are shown on thedisplay:● Duration of washing programme in hours andminutes, after you have

15The wash programme can be delayed from 30 min -60 min - 90 min, 2 hours and then by 1 hour up toa maximum of 20 hours by means of this button.If you

16Programme informationSoakThis is a special programme for heavily soiled laundry.The machine performs a soak of about 30 minutes at30°C. At the end o

17Using the washing machineBefore the first wash, we recommend that you pour 2litres of water into the main wash compartment ofthe detergent drawer i

186. Select the spin speed or“None” optionPress the “Spin” button repeatedly in order to selectthe desired spin speed or the “None” option. Therelevan

1912.How to interrupt aprogrammeDepress the “Start/Pause” button to interrupt aprogramme which is running, the corresponding lightstarts to flash. Dep

2Installation●This appliance is heavy. Care should be taken whenmoving it.●It is dangerous to alter the specifications or attemptto modify this produc

20Hints & Tips on WashingDo NOT overload the machine. Weigh the laundry thefirst few times you use the appliance. The average weights of the most

21Wash Care SymbolsWash care labels inside garments recommend how to launder your clothes with the best results. The care labellingcode is in line wit

22Washing programmesThe “Economy Cottons 60° ” is the reference programme for the data entered in the energy label, in compliancewith EEC 92/75 standa

23ProgrammeProgrammedescriptionAvailable optionsLoadEnergykWhWaterlitresConsumptions*Soak for 30 minutesat 30°CSoak7 Kg 0.45 19460.13 rinsesLong spin

24Maintenance and CleaningYou must DISCONNECT the appliance from theelectricity supply, before you can carry out anycleaning or maintenance work.Desca

25• When no more water comes out, unscrew the pumpcover and remove it. Always keep a rag nearby to dryup spillage of water when removing the cover.•

26Something Not WorkingPlease carry out the following checks before contacting your local Service Force agent.IMPORTANT: if you call out an engineer t

27SymptomThe door will not openSolution●The water level is above the bottom edge of the door.●The machine is heating the water.●The drum is turning.In

John Lewis Partnership171 Victoria StreetLondon SW1E 5NNwww.johnlewis.com132 973 31014/07 132973310.qxd 02/04/2007 11.25 Pagina 28

3Environmental Information●After unpacking please dispose of packaging withdue regard to safety and the environment.●Materials marked with the symbol

4ContentsFor the UserImportant Safety Information 2-3Installation 2Child safety 2Description of the Appliance 5Detergent dispenser drawer 5Child safet

5Description of the Appliance1 Detergent dispenser drawer2 Control panel3 Door handle4 Drain pump5 Adjustable feetDetergent dispenser drawerPrewashMai

6InstallationTechnical SpecificationsIt is dangerous to alter the specifications orattempt to modify this product in any way.Care must be taken to ens

7UnpackingAll transit bolts and packing must be removedbefore using the appliance.Keep all packaging away from children.You are advised to keep all th

8Plumbing InYour new washing machine has been designed to bepermanently plumbed in to your home’s water supplyand drainage system. However, if this is

9The drain hose may be extended to a maximum of 4metres. An additional drain hose and joining piece isavailable from your local Service Force Centre.
