JLWMS 16051600 spin washing machineInstruction manual

people who are allergic to detergents, and inareas where the water is very soft.Quick (8)This option can be used for lightly soiledlaundry. The washin

If the «Rinse Hold» or «Quiet»option has been selected the «Doorlock» light is on, the «Start/Pause»button light goes out and the displayshows a flash

First use• Ensure that the electrical andwater connections comply withthe installation instructions.• Remove the polystyrene block andany material fro

Daily useLoad the laundryOpen the door by carefully pulling the doorhandle outwards. Place the laundry in thedrum, one item at a time, shaking them ou

Pressing the corresponding buttons tochange those values. The green pilot light ofthe button 9 starts flashing.The dial can be turned either clockwise

•Press 9 button again.Cancelling the delayed start•Press button 9.• Press «Delay start» button once until thesymbol «0’» is displayed.•Press button 9

End of programmeAt the end of the programme, the washingmachine stops automatically, the button 9light and the Door lock light go off. Thedisplay show

Removing stainsStubborn stains may not be removed by justwater and detergent. It is therefore advisableto treat them prior to washing.Blood: treat fre

Follow the product manufacturers’instructions on quantities to use.Use less detergent if:• you are washing a small load• the laundry is lightly soiled

Programme - Maximum and MinimumTemperature - Cycle Description - MaximumSpin Speed - Maximum Fabrics Load - Type ofLaundryOptionsDetergentCompartmentC

Safety informationIt is most important that this instruction book should be retained withthe appliance for future reference. Should the appliance be

Programme - Maximum and MinimumTemperature - Cycle Description - MaximumSpin Speed - Maximum Fabrics Load - Type ofLaundryOptionsDetergentCompartmentS

Programme - Maximum and MinimumTemperature - Cycle Description - MaximumSpin Speed - Maximum Fabrics Load - Type ofLaundryOptionsDetergentCompartmentW

Programme - Maximum and MinimumTemperature - Cycle Description - MaximumSpin Speed - Maximum Fabrics Load - Type ofLaundryOptionsDetergentCompartmentR

Technical dataDimensions WidthHeightDepthDepth (Overall dimensions)60 cm85 cm60 cm63 cmElectrical connectionVoltage - Overall power - FuseInformation

Care and cleaningYou must DISCONNECT the appliancefrom the electricity supply, before you cancarry out any cleaning or maintenance work.DescalingThe w

Cleaning the drawerrecessHaving removed the drawer, use a smallbrush to clean the recess, ensuring that allwashing powder residue is removed fromthe u

• the appliance makes an unusual noiseduring draining due to objects such assafety pins, coins etc. blocking the pump.• a problem with water draining

9. Put the cap back on the emergencyemptying hose and place the latter backin its seat.10. Replace the filter into the pump byinserting it correctly i

6. Clean the filter in the valve with a stiffbrush or with the piece of cloth.7. Screw the hose back to the machineand make sure the connection is tig

InstallationUnpackingAll transit bolts and packing must beremoved before using the appliance.You are advised to keep all transit devices sothat they c

• Wash small items such as socks, laces,washable belts etc in a washing bag orpillow case as it is possible for such itemsto slip down between the tub

5. Open the porthole and remove thepolystyrene block fitted on the doorseal.6. Fill the smaller upper hole and the twolarge ones with the correspondin

of connectors are available from goodhardware stores and plumbers merchants tosuit most domestic plumbing. Any alterationto your existing plumbing mus

Warning! Installation shouldcomply with local waterauthority and buildingregulations’ requirements.The appliance must beconnected to a cold watersuppl

If the outlet spigot has not been usedbefore, remove any blanking plug that maybe in place.Push the drain hose onto the spigot andsecure with a clip,

SHOWERBATHBIDETWASHINGMACHINEDISHWASHERRAINWATER‘RUN-OFF’SURFACE WATERDRAINS & SEWERSUNTREATEDDISCHARGERIVERRIVERFOUL DRAINFOUL SEWERSSEWAGETREATM

Important! Information on theelectrical connection is given on therating plate on the inner edge of theappliance door.The appliance is supplied with a

What to do if…Certain problems are due to lack of simplemaintenance or oversights, which can besolved easily without calling out an engineer.Before co

Problem Possible cause/SolutionThe machine does not fill:The water tap is closed (E10).• Open the water tap.The inlet hose is squashed or kinked (E10)

Problem Possible cause/SolutionUnsatisfactory washingresults:Too little detergent or unsuitable detergent has been used.• Increase the detergent quant

Problem Possible cause/SolutionThe display shows thealarm code EFO:Anti-flooding system has been activated.• Disconnect the appliance, close the water

• The users should always check that theyhave not left their gas lighters (disposableor otherwise) in their clothing.• Never tumble dry items that hav

inexperienced persons may cause injury orserious malfunctioning. Contact your localJohn Lewis Branch.Environment concernsThe symbol on the product o

41

42

43

John Lewis Partnership171 Victoria StreetLondon SW1E 5NNwww.johnlewis.com132945911-A-092011

ContentsOperating instructionsSafety information 2General safety 2Installation 3Use 3Child safety 4Product description 7Detergent dispenser dr

How to open the door during the cycle of aprogramme 15End of programme 16Helpful hints and tips 16Washing programmes 18Technical data 23Consumpt

Product description1 Detergent dispenser drawer2 Control panel3 Door opening handle4 Rating plate5 Drain pump6 Adjustable feet1 235467

Detergent dispenser drawer Compartment for detergent used forprewash and soak phase or for stain removerused during the stain action phase (ifavailabl

12345678910111Detergent dispenser drawer2Programme selector dial3Display4SPIN reduction button5EASY IRON button6OPTIONS button7EXTRA RINSE button8QUIC
